Upper fork plate for various EBR telescopic forks (hydraulic, Staco etc.). However, not suitable for EBR Harry forks, as these have Ø 30 mm stanchions.
Ø for head tube: 25.6 mm
Ø fork stanchions (clamped): 28.5 mm
Distance between fork legs: 150 mm
Hole spacing for clamp handlebars: 30 mm
Material: cast aluminum, painted black.
You can find more fork parts in the accessories section.
Branded product from the Italian manufacturer EBR.
Details
| Manufacturer | EWC |
| Material | Aluminum |
| Color | black |
| Surface | varnished |
| Ø spars | 28 mm |
Suitable for the following models
| Puch | |
| Sachs | |
| Pony / Cilo (Beta 521 & 512) | |
| Piaggio |
