GPO lifting plate 1 - 4 mm | Puch Maxi, X30 Sport, NG-2AH

Large outlet seal with metal ring

Material: Sealing carton · Material: Sheet metal (steel) · Area of application: Tuning · Reinforced: Yes · Ø outlet inside: 27 mm · Thickness: 2.1 mm · Place of use: Outlet · Ø screw holder: 6.3 mm · Hole spacing outlet: 42.5 mm

Gas cable Ø 1.25 mm x 220 cm (cylindrical nipple) Bing

Ø nipple: 3 mm · Nipple length: 5 mm · Manufacturer: Made in Germany · Area of application: Standard · Material: Steel · Surface: blue galvanized · Number of components: 1 pcs · Ø Stranded wire: 1.25 mm · Nipple shape: Cylinder · Cable length: 2200 mm

GPO gasket cylinder base 0.35 mm original | Puch

Ø inside: 47 mm · Manufacturer: GPO · Material: Oiled paper · Area of application: Standard · Nominal diameter: 47 mm · Thickness: 0.3 mm · Place of use: Cylinder base · Hole pattern [mm]: 44 x 44 · Puch spare part no.: 349.3.10.013.1

Motorex Automatic Motor Oil (ATF) 450 ml

Manufacturer: Motorex · Area of application: Gearbox lubrication with clutch · Oil type: ATF Dextron 3 (DEXIII) · Contents [ml]: 450 ml · Gearbox type: Automatic machine · Temperature resistance (min.): -45 - 200 °C · Pony spare part no.: A2080 · Sachs spare part no.: 0263 014 002

MBR Retaining plate, oil seal, ignition side Racing

Number of fixing points: 4 pcs · Ø inside: 25.3 mm · Ø outside: 89.4 mm · Manufacturer: MBR · Material: Chrome steel (stainless steel) · Area of application: Tuning · Surface: brushed · Color: silver

GPO gasket cylinder base 0.5 mm | Puch

Ø inside: 49 mm · Manufacturer: GPO · Material: Oiled paper · Area of application: Standard · Nominal diameter: 49 mm · Thickness: 0.5 mm · Place of use: Cylinder base · Hole pattern [mm]: 44 x 44 · Puch spare part no.: 349.3.10.013.1

swiing® ingenious crankshaft High End with mounted bearings (Version 2.0) | Puch E50

Manufacturer: swiing® ingenious parts · Weight: 968 g · Material: Aluminum · Area of application: High End · Area of application: Racing · Material: Steel · Area of application: Tuning · Cheek type: Full cheeks · Crankshaft stroke: 43 mm · Ø piston pin (B): 12 mm · Thread type: MF10x1 (fine pitch thread) · Connecting rod length center-center: 90 mm · Total length of crankpin on clutch side: 74 mm · Total length crankpin ignition side: 66 mm · Ø crank webs: 69.9 mm · Ø Connecting rod eye: 15 mm · Ø Bearing seat (clutch side): 17 mm · Ø Bearing seat (ignition side): 17 mm · Thread length: 11 mm · Thread length: 15 mm · Dimension needle bearing: 12 / 15 x 14.2 mm (axe 12) · Wide crank webs: 34 mm · Length 1st paragraph: 9 mm · Length 2nd paragraph: 14.5 mm · Length 3rd paragraph: 25 mm · Ø 1st step (on the coupling side): 22 mm · Ø 2nd shoulder (on the clutch side): 17 mm · Ø 3rd step (on the clutch side): 15 mm · Length of shoulder (ignition side): 26.3 mm · Number of gears: 1 pcs

Airsal gasket set cylinder 46 mm Puch

Manufacturer: Airsal · Area of application: Tuning · Ø cylinder: 46 mm · Number of components: 4 pcs · Hole spacing inlet: 32 - 38 mm · Hole pattern [mm]: 44 x 44 mm · Decompressor: No · Hole spacing outlet: 42 mm

swiing® ingenious crankshaft High End C3/4 & Viton (+1 mm stroke) (Version 2.0) | Puch E50

Manufacturer: swiing® ingenious parts · Weight: 970 g · Area of application: High End · Material: Steel · Cheek type: Full cheeks · Crankshaft stroke: 44 mm · Ø piston pin (B): 12 mm · Thread type: MF10x1 (fine pitch thread) · Connecting rod length center-center: 90 mm · Total length of crankpin on clutch side: 74 mm · Total length crankpin ignition side: 66 mm · Ø crank webs: 69.9 mm · Ø Connecting rod eye: 15 mm · Ø Bearing seat (clutch side): 17 mm · Ø Bearing seat (ignition side): 17 mm · Thread length: 11 mm · Thread length: 15 mm · Dimension needle bearing: 12 / 15 x 14.2 mm (axe 12) · Wide crank webs: 34 mm · Length 1st paragraph: 9 mm · Length 2nd paragraph: 14.5 mm · Ø 1st step (on the coupling side): 22 mm · Ø 2nd shoulder (on the clutch side): 17 mm · Ø 3rd step (on the clutch side): 15 mm · Length of shoulder (ignition side): 26.3 mm · Number of gears: 1 pcs
