Toolbox | Piaggio Ciao PX

CIF Clamping screw front brake | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: CIF · Area of application: Standard · Material: Steel · Surface: blue galvanized · Total length: 25 mm · Drive: External hexagon · Thread length: 19.5 mm · Screw head: Hexagon · Ø outside: 11 mm · Number of components: 6 pcs · Width across flats SW: 11 mm · Thread type: M7x1 (standard thread)

Pedals angular | Piaggio Ciao. SI, Bravo

Material: Plastic · Color: black · Surface: ribbed · Thread type: FG14.3 (9/16" 20G) · Total length: 118 mm · Drive: Outer edge · Width: 51 mm · Height: 29 mm · Width across flats SW: 15 mm · Reflectors: Yes

swiing® revival screw footboard M6 Inox | Piaggio Ciao

Manufacturer: swiing® revival parts · Material: Chrome steel (stainless steel) · Total length: 17 mm · Drive: Slot · Screw head: Lens head · Ø External head: 13.8 mm · Thread type: M6x1 (standard thread)

Dell'Orto 13/13 SHA carburetor hand choke | Piaggio Ciao PX, C24

Manufacturer: Dell'Orto · Camouflaged: No · Material: Aluminum · Color: black · Carburetor type: SHA (type 3) · Nominal diameter: 13 mm · Ø Internal connection: 16 mm · Ø without reducing sleeve: 18 mm · Ø Inside entrance: 13 mm · Ø Output inside: 13 mm · Ø Air filter connection: 50.8 mm · Ø fuel hose connection: 5.2 mm · Ø fuel hose connection: 6 mm · Mixed oil connection: No · Vacuum connection: No · Choke control: Hand choke · Nozzle thread: M5 · Nozzle size: 66 · Mounting type: Plug connection clamped · Total length: 46 mm · Width: 60 mm · Height: 96 mm · Area of application: Tuning

Lockable fuel filler cap | Piaggio Ciao

Ø External head: 54 mm · Material: Plastic · Color: black · Lockable: Yes · Vented: Yes · Height: 105 mm · Fuel filler cap: Plug 33 mm

CIF screw set side protection | Piaggio Ciao

Manufacturer: CIF · Area of application: Standard · Material: Spring steel · Material: Steel · Color: silver · Surface: blue galvanized · Surface: raw · Drive: Slot · Screw head: Lens head · Number of components: 12 pcs

Emblem "Piaggio" Ø 30 mm steering head | Piaggio Ciao

Manufacturer: Made in Italy · Material: Aluminum · Diameter: 30 mm · Rear side texture: Adhesive · Mounting type: glue · Piaggio spare part no.: 574771

Splash guard front fender | Piaggio Ciao

Manufacturer: Made in Italy · Material: Rubber · Color: black · Total length: 115 mm · Width: 90 mm · Number of fixing points: 2 pcs · Ø mounting hole: 3.3 mm · Mounting type: Rivets · Piaggio spare part no.: 100446

Fuse plate emblem original | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: Piaggio · Total length: 13 mm · Width: 8 mm · Clamping range: 3 - 5 mm · Piaggio spare part no.: 008108
