Seals

GPO Ø 43 mm "Pomodoro" cylinder kit | Sachs 503

Nominal diameter: 43 mm · Manufacturer: GPO · Material: Gray cast iron · Displacement: 63 ccm · Crankshaft stroke: 43 mm · Hole spacing inlet: 32 mm · Ø cylinder neck: 45 mm · Ø outlet inside: 22 mm · Ø Outlet outside: 26 mm · Ø Inlet inside: 19 mm · Area of application: Tuning · Thread inlet: M6x1 (standard thread) · Hole pattern [mm]: 40 x 60 / 37 x 37 · Ø piston pin (B): 12 mm · Outlet type: clamped

swiing® ingenious 41 mm cylinder kit tuning diaphragm | Sachs 50/2 (CH)

Nominal diameter: 41 mm · Manufacturer: GPO · Manufacturer: swiing® ingenious parts · Material: Gray cast iron · Surface: sandblasted · Displacement: 55 ccm · Crankshaft stroke: 42 mm · Ø cylinder neck: 44 mm · Ø Outlet outside: 35 mm · Ø outlet inside: 26 mm · Ø Inlet inside: 19 mm · Inlet window: 57.5 x 19 · Thread inlet: M5x0.8 (standard thread) · Hole spacing inlet: 68 mm · Ø piston pin (B): 12 mm · Outlet type: Union nut · Thread outlet: M35x2 (standard thread) · Number of fixing points: 4 pcs · Hole pattern [mm]: 60 x 40 / 37 x 37 · Camouflaged: Yes · Area of application: Tuning

GPO Ø 41 mm "Pomodoro" cylinder kit | Sachs 503

Manufacturer: GPO · Material: Gray cast iron · Area of application: Tuning · Displacement: 55 ccm · Crankshaft stroke: 43 mm · Ø piston pin (B): 12 mm · Hole spacing inlet: 32 mm · Nominal diameter: 41 mm · Ø cylinder neck: 45 mm · Ø Outlet outside: 26 mm · Ø outlet inside: 22 mm · Ø Inlet inside: 19 mm · Thread inlet: M5x0.8 (standard thread) · Hole pattern [mm]: 40 x 60 / 37 x 37 · Outlet type: clamped

AKOA 41 mm cylinder kit | Sachs 503 2AL, AAL, 2BL, ABL

Nominal diameter: 41 mm · Manufacturer: AKOA · Material: Aluminum · Surface: nikasil-coated · Displacement: 57 ccm · Crankshaft stroke: 43 mm · Ø cylinder neck: 45.5 mm · Ø Outlet outside: 25.8 mm · Ø outlet inside: 18.5 mm · Ø Inlet inside: 14 mm · Thread inlet: M6x1 (standard thread) · Hole spacing inlet: 32 mm · Ø piston pin (B): 12 mm · Number of fixing points: 4 pcs · Outlet type: clamped · Hole pattern [mm]: 40 x 60 / 37 x 37 · Decompressor: No · Area of application: Tuning

AKOA 38 mm cylinder kit | Sachs 503 2AL, AAL, 2BL, ABL

Manufacturer: AKOA · Material: Aluminum · Area of application: Standard · Surface: nikasil-coated · Displacement: 50 ccm · Crankshaft stroke: 43 mm · Ø piston pin (B): 12 mm · Nominal diameter: 38 mm · Ø cylinder neck: 45.5 mm · Ø Outlet outside: 25.8 mm · Ø Inlet inside: 14 mm · Ø outlet inside: 18.5 mm · Thread inlet: M6x1 (standard thread) · Number of fixing points: 4 pcs · Hole pattern [mm]: 40 x 60 / 37 x 37 · Outlet type: clamped · Decompressor: No · Hole spacing inlet: 32 mm

BAD ASS Ø 41 mm "Pandora" tuning cylinder | Sachs 503, 50/2, 502

Manufacturer: BAD ASS · Number of fixing points: 4 pcs · Material: Gray cast iron · Surface: sandblasted · Area of application: Tuning · Displacement: 55 ccm · Crankshaft stroke: 42 mm · Nominal diameter: 41 mm · Ø cylinder neck: 45 mm · Ø Outlet outside: 26 mm · Ø Inlet inside: 19 mm · Thread inlet: M6x1 (standard thread) · Ø outlet inside: 23 mm · Ø piston pin (B): 12 mm · Outlet type: clamped · Hole spacing inlet: 32 mm · Hole pattern [mm]: 40 x 60 / 37 x 37 · Camouflaged: No

AKOA 40 mm cylinder kit | Sachs 503 2AL, AAL, 2BL, ABL

Manufacturer: AKOA · Area of application: Tuning · Material: Aluminum · Surface: nikasil-coated · Crankshaft stroke: 43 mm · Displacement: 54 ccm · Ø cylinder neck: 45.5 mm · Ø Outlet outside: 25.8 mm · Nominal diameter: 40 mm · Number of fixing points: 4 pcs · Ø Inlet inside: 14 mm · Ø outlet inside: 18.5 mm · Hole spacing inlet: 32 mm · Ø piston pin (B): 12 mm · Thread inlet: M6x1 (standard thread) · Hole pattern [mm]: 40 x 60 / 37 x 37 · Decompressor: No · Outlet type: clamped

swiing® ingenious 41 mm cylinder kit Racing (Version 2.0) fan-cooled | Sachs 50/2 (CH)

Nominal diameter: 41 mm · Manufacturer: swiing® ingenious parts · Material: Aluminum · Surface: sandblasted · Displacement: 55 ccm · Crankshaft stroke: 42 mm · Ø cylinder neck: 45 mm · Ø outlet inside: 20.5 mm · Ø Inlet inside: 15.3 mm · Thread inlet: M6x1 (standard thread) · Hole spacing inlet: 31 mm · Ø piston pin (B): 12 mm · Outlet type: Union nut · Thread outlet: M35x2 (standard thread) · Number of fixing points: 4 pcs · Hole pattern [mm]: 60 x 40 / 37 x 37 · Camouflaged: No · Area of application: Racing

AKOA wide wall 45 mm cylinder kit | Sachs 503 AB, AC, ADV

Manufacturer: AKOA · Material: Aluminum · Surface: nikasil-coated · Surface: varnished · Area of application: Tuning · Displacement: 70 ccm · Crankshaft stroke: 44 mm · Nominal diameter: 45 mm · Ø cylinder neck: 50.5 mm · Ø cylinder neck: 52 mm · Ø Inlet inside: 23.5 mm · Thread inlet: M6x1 (standard thread) · Ø outlet inside: 29 mm · Ø piston pin (B): 12 mm · Hole spacing outlet: 50.5 mm · Outlet type: slanted · Hole spacing inlet: 36 mm · Thread outlet: M6x1 (standard thread) · Hole pattern [mm]: 56 x 56 · Decompressor: MF12x1.25 · Alternative version of the Pony Spare part no.: A2868

swiing 38 mm cylinder kit tuning diaphragm | Sachs 50/2 (CH)

Nominal diameter: 38 mm · Manufacturer: Meteor · Manufacturer: swiing · Material: Gray cast iron · Surface: sandblasted · Displacement: 50 ccm · Crankshaft stroke: 42 mm · Thread inlet: M5x0.8 (standard thread) · Hole spacing inlet: 31 mm · Ø piston pin (B): 12 mm · Outlet type: Union nut · Thread outlet: M35x2 (standard thread) · Number of fixing points: 4 pcs · Hole pattern [mm]: 60 x 40 / 37 x 37 · Camouflaged: Yes · Area of application: Tuning

BAD ASS Diablo cylinder Ø 41 mm | Sachs 502, 50/2, 50/3, 50/4

Nominal diameter: 41 mm · Manufacturer: BAD ASS · Material: Gray cast iron · Area of application: Tuning · Surface: raw · Displacement: 55 ccm · Crankshaft stroke: 42 mm · Ø cylinder neck: 46 mm · Ø Outlet outside: 40 mm · Ø outlet inside: 28 mm · Inlet window: 17 x 15 mm · Thread inlet: M5x0.8 (standard thread) · Number of fixing points: 4 pcs · Hole spacing inlet: 31 mm · Ø piston pin (B): 12 mm · Outlet type: Union nut · Thread outlet: MF40x1.5 (fine pitch thread) · Hole pattern [mm]: 60 x 40 / 51 x 40 / 37 x 37 · Camouflaged: No

Airsal 43.5 mm cylinder kit incl. mounting parts | Sachs 504, 505, 508

Manufacturer: Airsal · Material: Aluminum · Camouflaged: No · Surface: sandblasted · Nominal diameter: 43.5 mm · Crankshaft stroke: 44 mm · Ø cylinder neck: 50 mm · Ø Outlet outside: 26 mm · Ø Inlet inside: 14 mm · Hole spacing inlet: 31 mm · Inlet window: 23.8 x 14.8 · Thread inlet: M6x1 (standard thread) · Number of fixing points: 4 pcs · Ø piston pin (B): 12 mm · Decompressor: M10x1.5 · Hole pattern [mm]: 56 (61) x 56 · Outlet type: clamped · Area of application: Tuning

AKOA wide wall 38 mm cylinder kit original | Sachs 503 AB, AC, ADV (A2868)

Nominal diameter: 38 mm · Manufacturer: AKOA · Material: Aluminum · Surface: nikasil-coated · Surface: varnished · Displacement: 50 ccm · Crankshaft stroke: 44 mm · Hole spacing inlet: 36 mm · Ø cylinder neck: 50.5 mm · Ø cylinder neck: 52 mm · Ø outlet inside: 11 mm · Ø outlet inside: 19.5 mm · Ø Outlet outside: 23 mm · Area of application: Standard · Inlet window: 18x7 mm · Hole spacing outlet: 50.5 mm · Thread inlet: M6x1 (standard thread) · Ø piston pin (B): 12 mm · Outlet type: slanted · Thread outlet: M6x1 (standard thread) · Decompressor: MF12x1.25 · Pony spare part no.: A2868

swiing 41 mm cylinder kit Racing fan-cooled (Version 2.0) | Sachs 50/2, 50/3, 50/4 (DE)

Nominal diameter: 41 mm · Manufacturer: swiing · Material: Aluminum · Surface: sandblasted · Displacement: 55 ccm · Crankshaft stroke: 42 mm · Thread inlet: M5x0.8 (standard thread) · Hole spacing inlet: 31 mm · Ø piston pin (B): 12 mm · Outlet type: Union nut · Thread outlet: M35x2 (standard thread) · Number of fixing points: 4 pcs · Hole pattern [mm]: 51 x 40 · Camouflaged: No · Area of application: Racing

BAD ASS Ø 43 mm "Pandora" BigBore tuning cylinder | Sachs 503, 50/2, 502

Nominal diameter: 43 mm · Manufacturer: BAD ASS · Material: Gray cast iron · Area of application: Tuning · Surface: sandblasted · Displacement: 63 ccm · Crankshaft stroke: 42 mm · Ø cylinder neck: 45 mm · Ø Outlet outside: 26 mm · Ø outlet inside: 23 mm · Ø Inlet inside: 19 mm · Thread inlet: M6x1 (standard thread) · Number of fixing points: 4 pcs · Hole spacing inlet: 32 mm · Ø piston pin (B): 12 mm · Outlet type: clamped · Hole pattern [mm]: 40 x 60 / 37 x 37 · Camouflaged: No

AKOA wide wall 38 mm cylinder kit Sport | Sachs 503 AB, AC, ADV (A2868)

Manufacturer: AKOA · Area of application: Performance · Material: Aluminum · Surface: nikasil-coated · Surface: varnished · Crankshaft stroke: 44 mm · Displacement: 50 ccm · Ø cylinder neck: 50.5 mm · Ø cylinder neck: 52 mm · Nominal diameter: 38 mm · Ø Inlet inside: 23.5 mm · Ø outlet inside: 29 mm · Hole spacing inlet: 36 mm · Ø piston pin (B): 12 mm · Thread inlet: M6x1 (standard thread) · Hole pattern [mm]: 56 x 56 · Decompressor: MF12x1.25 · Hole spacing outlet: 50.5 mm · Outlet type: slanted · Thread outlet: M6x1 (standard thread) · Alternative version of the Pony Spare part no.: A2868

swiing 41 mm cylinder kit | Sachs 50/3, 50/4 LKH (square inlet)

Nominal diameter: 41 mm · Manufacturer: swiing · Material: Gray cast iron · Surface: sandblasted · Displacement: 55 ccm · Crankshaft stroke: 42 mm · Thread inlet: M5x0.8 (standard thread) · Hole spacing inlet: 31 mm · Ø piston pin (B): 12 mm · Outlet type: Union nut · Thread outlet: MF40x1.5 (fine pitch thread) · Number of fixing points: 4 pcs · Hole pattern [mm]: 51 x 40 / 37 x 37 · Camouflaged: No · Area of application: Tuning

swiing 38 mm cylinder kit Racing fan-cooled | Sachs 50/2 (CH)

Nominal diameter: 38 mm · Manufacturer: swiing · Material: Aluminum · Surface: sandblasted · Displacement: 50 ccm · Crankshaft stroke: 42 mm · Thread inlet: M5x0.8 (standard thread) · Hole spacing inlet: 31 mm · Ø piston pin (B): 12 mm · Outlet type: Union nut · Thread outlet: M35x2 (standard thread) · Number of fixing points: 4 pcs · Hole pattern [mm]: 60 x 40 · Camouflaged: No · Area of application: Racing

GPO 41 mm cylinder | Sachs 50/3, 50/4 (square inlet) fan-cooled (DE)

Nominal diameter: 41 mm · Manufacturer: GPO · Material: Gray cast iron · Surface: raw · Displacement: 55 ccm · Crankshaft stroke: 42 mm · Ø Outlet outside: 40 mm · Hole spacing inlet: 31 mm · Number of fixing points: 4 pcs · Outlet type: Union nut · Cooling type: Fan air cooling · Area of application: Tuning

GPO 41 mm cylinder kit fan-cooled diaphragm | Sachs 50/2, 50/3, 50/4 (DE)

Nominal diameter: 41 mm · Manufacturer: GPO · Material: Gray cast iron · Surface: sandblasted · Displacement: 55 ccm · Crankshaft stroke: 42 mm · Thread inlet: M5x0.8 (standard thread) · Hole spacing inlet: 67 mm · Ø piston pin (B): 12 mm · Outlet type: Union nut · Thread outlet: M35x2 (standard thread) · Number of fixing points: 4 pcs · Hole pattern [mm]: 51 x 40 · Camouflaged: No · Area of application: Tuning

Athena 45 mm cylinder kit incl. mounting parts | Sachs (504), 505, 508

Manufacturer: Athena · Material: Aluminum · Camouflaged: No · Surface: sandblasted · Crankshaft stroke: 44 mm · Nominal diameter: 45 mm · Ø piston pin (B): 12 mm · Ø cylinder neck: 51.7 mm · Ø Outlet outside: 25.9 mm · Ø Inlet inside: 14.3 mm · Inlet window: 23.4 x 12.6 · Thread inlet: M6x1 (standard thread) · Ø outlet inside: 19.5 mm · Number of fixing points: 4 pcs · Hole spacing outlet: 50 mm · Decompressor: M10x1.5 · Outlet type: clamped · Outlet type: straight · Hole spacing inlet: 31.5 mm · Thread outlet: M8x1.25 (standard thread) · Hole pattern [mm]: 56 (61) x 56 · Area of application: Tuning

GPO 38 mm cylinder kit slotted | Sachs 50/2, 50/3, 50/4 fan-cooled (DE)

Nominal diameter: 38 mm · Manufacturer: GPO · Material: Gray cast iron · Surface: sandblasted · Displacement: 50 ccm · Crankshaft stroke: 42 mm · Thread inlet: M5x0.8 (standard thread) · Hole spacing inlet: 31 mm · Ø piston pin (B): 12 mm · Outlet type: Union nut · Thread outlet: M35x2 (standard thread) · Number of fixing points: 4 pcs · Hole pattern [mm]: 51 x 40 / 37 x 37 · Camouflaged: No · Area of application: Tuning

BAD ASS 38 mm cylinder kit, slotted | Sachs 50/2 (CH)

Nominal diameter: 38 mm · Manufacturer: BAD ASS · Material: Gray cast iron · Area of application: Standard · Surface: sandblasted · Displacement: 50 ccm · Crankshaft stroke: 42 mm · Thread inlet: M5x0.8 (standard thread) · Hole spacing inlet: 31 mm · Ø piston pin (B): 12 mm · Outlet type: Union nut · Thread outlet: M35x2 (standard thread) · Number of fixing points: 4 pcs · Hole pattern [mm]: 60 x 40 / 37 x 37 · Camouflaged: Yes · Alternative version of the Pony Spare part no.: A2539 · Alternative version of Sachs spare part no.: 0286 114 215

GPO 41 mm cylinder kit (square intake) | Sachs 50/3, 50/4 fan-cooled

Nominal diameter: 41 mm · Manufacturer: GPO · Material: Gray cast iron · Surface: sandblasted · Displacement: 55 ccm · Crankshaft stroke: 42 mm · Thread inlet: M5x0.8 (standard thread) · Hole spacing inlet: 31 mm · Ø piston pin (B): 12 mm · Outlet type: Union nut · Thread outlet: MF40x1.5 (fine pitch thread) · Number of fixing points: 4 pcs · Hole pattern [mm]: 51 x 40 · Camouflaged: No · Area of application: Tuning

GPO 41 mm cylinder kit square inlet | Sachs 50/3, 50/4 LKH

Nominal diameter: 41 mm · Manufacturer: GPO · Area of application: Tuning · Material: Gray cast iron · Surface: sandblasted · Displacement: 55 ccm · Crankshaft stroke: 42 mm · Thread inlet: M5x0.8 (standard thread) · Hole spacing inlet: 31 mm · Ø piston pin (B): 12 mm · Outlet type: Union nut · Thread outlet: MF40x1.5 (fine pitch thread) · Number of fixing points: 4 pcs · Hole pattern [mm]: 51 x 40 · Camouflaged: No

Athena 48 mm cylinder kit | Sachs 503 AB, AC, ADV

Manufacturer: Athena · Material: Aluminum · Camouflaged: No · Surface: sandblasted · Crankshaft stroke: 43 mm · Nominal diameter: 48 mm · Displacement: 80 ccm · Ø piston pin (B): 12 mm · Ø Outlet outside: 26 mm · Thread inlet: M6x1 (standard thread) · Number of fixing points: 4 pcs · Outlet type: clamped · Outlet type: slanted · Thread outlet: M6x1 (standard thread) · Area of application: Tuning

swiing 41 mm tuning set diaphragm | Sachs 50/2 (CH)

Nominal diameter: 41 mm · Manufacturer: GPO · Manufacturer: NGK · Manufacturer: swiing · Manufacturer: swiing® ingenious parts · Manufacturer: swiing® revival parts · Displacement: 55 ccm · Crankshaft stroke: 42 mm · Thread inlet: M5x0.8 (standard thread) · Hole spacing inlet: 31 mm · Ø piston pin (B): 12 mm · Outlet type: Union nut · Thread outlet: M35x2 (standard thread) · Hole pattern [mm]: 60 x 40 · Decompressor: No · Camouflaged: Yes · Area of application: Tuning

swiing 38 mm cylinder kit Racing fan-cooled | Sachs 50/2, 50/3, 50/4 (DE)

Nominal diameter: 38 mm · Manufacturer: swiing · Material: Aluminum · Surface: sandblasted · Displacement: 50 ccm · Crankshaft stroke: 42 mm · Thread inlet: M5x0.8 (standard thread) · Hole spacing inlet: 31 mm · Ø piston pin (B): 12 mm · Outlet type: Union nut · Thread outlet: M35x2 (standard thread) · Number of fixing points: 4 pcs · Hole pattern [mm]: 51 x 40 · Camouflaged: No · Area of application: Racing

swiing® ingenious 41 mm everyday tuning set diaphragm | Sachs 50/2 (CH)

Manufacturer: GPO · Manufacturer: NGK · Manufacturer: swiing® ingenious parts · Material: Gray cast iron · Displacement: 55 ccm

Athena 38 mm cylinder kit (incl. mounting parts) | Sachs (504), 505, 508

Nominal diameter: 38 mm · Manufacturer: Athena · Material: Aluminum · Surface: sandblasted · Displacement: 50 ccm · Crankshaft stroke: 44 mm · Ø cylinder neck: 51.7 mm · Ø outlet inside: 28 mm · Inlet window: 23.4 x 13 · Thread inlet: M6x1 (standard thread) · Hole spacing inlet: 31.5 mm · Ø piston pin (B): 12 mm · Outlet type: clamped · Outlet type: straight · Hole spacing outlet: 50 mm · Thread outlet: M8x1.25 (standard thread) · Number of fixing points: 4 pcs · Hole pattern [mm]: 56 (61) x 56 · Decompressor: M10x1.5 · Camouflaged: No · Area of application: Tuning

38 mm cylinder kit 45 km/h version | Sachs (504), 505, 508

Material: Aluminum · Nominal diameter: 38 mm · Displacement: 50 ccm · Ø piston pin (B): 12 mm · Ø cylinder neck: 44.4 mm · Ø cylinder neck: 52 mm · Ø Outlet outside: 25.9 mm · Ø outlet inside: 22.4 mm · Number of fixing points: 4 pcs · Inlet window: 23.2 x 12.8 · Thread inlet: M6x1 (standard thread) · Hole pattern [mm]: 55 x 55 · Decompressor: M10x1.5 · Outlet type: straight · Hole spacing inlet: 31.5 mm

Athena 38 mm cylinder kit without mounting parts | Sachs (504), 505, 508

Manufacturer: Athena · Camouflaged: No · Material: Aluminum · Surface: sandblasted · Crankshaft stroke: 44 mm · Displacement: 50 ccm · Nominal diameter: 38 mm · Ø cylinder neck: 51.7 mm · Ø outlet inside: 28.3 mm · Hole spacing inlet: 32 mm · Ø piston pin (B): 12 mm · Inlet window: 23.6 x 12.8 / 16.5 · Hole spacing outlet: 50 mm · Thread inlet: M6x1 (standard thread) · Number of fixing points: 4 pcs · Decompressor: M10x1.5 · Hole pattern [mm]: 56/61 x 56 · Outlet type: straight · Thread outlet: M8x1.25 (standard thread) · Area of application: Tuning

GPO 38 mm cylinder kit diaphragm | Sachs 50/2, 50/3, 50/4 fan-cooled (DE)

Nominal diameter: 38 mm · Manufacturer: GPO · Material: Gray cast iron · Surface: sandblasted · Displacement: 50 ccm · Crankshaft stroke: 42 mm · Thread inlet: M5x0.8 (standard thread) · Hole spacing inlet: 67 mm · Ø piston pin (B): 12 mm · Outlet type: Union nut · Thread outlet: M35x2 (standard thread) · Number of fixing points: 4 pcs · Hole pattern [mm]: 51 x 40 / 37 x 37 · Camouflaged: No · Area of application: Tuning

Athena 48 mm cylinder kit incl. diaphragm | Sachs (504), 505, 508

Manufacturer: Athena · Material: Aluminum · Camouflaged: No · Surface: sandblasted · Crankshaft stroke: 44 mm · Nominal diameter: 48 mm · Ø piston pin (B): 12 mm · Ø cylinder neck: 51.8 mm · Ø Outlet outside: 26 mm · Ø Inlet inside: 14.7 mm · Ø Inlet inside: 17.8 mm · Inlet window: 31.9 x 36.2 · Thread inlet: M5x0.8 (standard thread) · Ø outlet inside: 19.4 mm · Number of fixing points: 4 pcs · Hole spacing outlet: 50 mm · Decompressor: M10x1.5 · Outlet type: clamped · Outlet type: straight · Hole spacing inlet: 32.5 mm · Thread outlet: M8x1.25 (standard thread) · Hole pattern [mm]: 56/60 x 56 · Area of application: Tuning

38 mm cylinder kit round intake | Sachs 50/3, 50/4

Material: Gray cast iron · Camouflaged: No · Surface: varnished · Nominal diameter: 38 mm · Crankshaft stroke: 43 mm · Displacement: 50 ccm · Ø piston pin (B): 12 mm · Thread inlet: M5x0.8 (standard thread) · Number of fixing points: 4 pcs · Outlet type: Union nut · Hole spacing inlet: 31 mm · Thread outlet: MF40x1.5 (fine pitch thread) · Hole pattern [mm]: 51 x 40 · Area of application: Tuning

Cylinder 38 mm diaphragm 2 lugs NOS | Sachs Saxonette

Nominal diameter: 41 mm · Manufacturer: Sachs · Material: Gray cast iron · Surface: raw · Displacement: 50 ccm · Crankshaft stroke: 42 mm · Ø cylinder neck: 43.8 mm · Ø outlet inside: 26.3 mm · Number of fixing points: 4 pcs · Inlet window: 56 x 18 · Thread inlet: M5x0.8 (standard thread) · Hole pattern [mm]: 51 x 40 mm / 37 x 37 mm · Hole spacing inlet: 67 mm · Outlet type: Union nut · Thread outlet: M35x2 (standard thread) · Area of application: Original · Decompressor: No

GPO 41 mm cylinder kit fan-cooled slot | Sachs 50/2, 50/3, 50/4 (DE)

Nominal diameter: 41 mm · Manufacturer: GPO · Material: Gray cast iron · Surface: sandblasted · Displacement: 55 ccm · Crankshaft stroke: 42 mm · Thread inlet: M5x0.8 (standard thread) · Hole spacing inlet: 31 mm · Ø piston pin (B): 12 mm · Outlet type: Union nut · Thread outlet: M35x2 (standard thread) · Number of fixing points: 4 pcs · Hole pattern [mm]: 51 x 40 · Camouflaged: No · Area of application: Tuning

38 mm cylinder kit square inlet | Sachs 50/3, 50/4

Material: Gray cast iron · Area of application: Tuning · Surface: sandblasted · Displacement: 50 ccm · Crankshaft stroke: 42 mm · Ø piston pin (B): 12 mm · Nominal diameter: 38 mm · Thread inlet: M5x0.8 (standard thread) · Number of fixing points: 4 pcs · Hole spacing inlet: 31 mm · Outlet type: Union nut · Thread outlet: M35x2 (standard thread) · Hole pattern [mm]: 51 x 40 · Camouflaged: No

38 mm cylinder kit diaphragm 2 warts NOS | Sachs Saxonette

Nominal diameter: 38 mm · Manufacturer: Sachs · Displacement: 50 ccm · Material: Gray cast iron · Crankshaft stroke: 42 mm · Surface: sandblasted · Thread inlet: M5x0.8 (standard thread) · Hole spacing inlet: 67 mm · Ø piston pin (B): 12 mm · Number of fixing points: 4 pcs · Outlet type: Union nut · Thread outlet: M35x2 (standard thread) · Hole pattern [mm]: 51 x 40 · Area of application: Original

38 mm cylinder kit 30 km/h version | Sachs 504, 505, (508)

Material: Aluminum · Displacement: 50 ccm · Ø cylinder neck: 49.4 mm · Ø cylinder neck: 51.9 mm · Ø Outlet outside: 25.9 mm · Nominal diameter: 38 mm · Number of fixing points: 4 pcs · Ø outlet inside: 22.5 mm · Hole spacing inlet: 31.5 mm · Ø piston pin (B): 12 mm · Inlet window: 18 x 13.4 · Thread inlet: M6x1 (standard thread) · Hole pattern [mm]: 55 x 55 · Decompressor: M10x1.5 · Outlet type: straight

Athena 48 mm cylinder kit without mounting parts | Sachs (504), 505, 508

Manufacturer: Athena · Material: Aluminum · Camouflaged: No · Surface: sandblasted · Crankshaft stroke: 44 mm · Nominal diameter: 48 mm · Ø piston pin (B): 12 mm · Ø cylinder neck: 51.6 mm · Number of fixing points: 4 pcs · Decompressor: M10x1.5 · Outlet type: clamped · Area of application: Tuning

Parmakit 48 mm cylinder kit tuning | Sachs 50 S, 501, 50/4 EKF

Nominal diameter: 38 mm · Manufacturer: Parmakit · Material: Aluminum · Surface: sandblasted · Displacement: 75 ccm · Ø piston pin (B): 14 mm · Outlet type: slanted · Number of fixing points: 4 pcs · Camouflaged: No · Area of application: Tuning

Parmakit 38 mm cylinder kit tuning | Sachs 50 S, 501, 50/4 EKF

Nominal diameter: 38 mm · Manufacturer: Parmakit · Material: Aluminum · Surface: sandblasted · Displacement: 50 ccm · Ø piston pin (B): 14 mm · Outlet type: slanted · Number of fixing points: 4 pcs · Camouflaged: No · Area of application: Tuning

42 mm cylinder kit | Sachs 5V

Nominal diameter: 42 mm · Material: Aluminum · Surface: sandblasted · Crankshaft stroke: 42 mm · Number of fixing points: 4 pcs · Thread inlet: M6x1 (standard thread) · Hole spacing inlet: 50 mm · Ø piston pin (B): 14 mm · Outlet type: slanted · Hole spacing outlet: 50 mm · Thread outlet: M6x1 (standard thread) · Hole pattern [mm]: 55 x 55 · Camouflaged: No · Area of application: Tuning

Power1 38 mm cylinder kit aluminum (square intake) | Sachs 50/3, 50/4 fan-cooled

Manufacturer: Power1 · Area of application: Tuning · Material: Aluminum · Surface: nikasil-coated · Crankshaft stroke: 43 mm · Displacement: 49 ccm · Ø cylinder neck: 44 mm · Camouflaged: No · Nominal diameter: 38 mm · Number of fixing points: 4 pcs · Hole spacing inlet: 31 mm · Ø piston pin (B): 12 mm · Inlet window: 16 x 18 · Thread inlet: M5x0.8 (standard thread) · Hole pattern [mm]: 51 x 40 / 37 x 37 · Outlet type: Union nut · Thread outlet: MF40x1.5 (fine pitch thread)

swiing® ingenious tuning set 38 mm | Sachs 503 (fan-cooled)

Nominal diameter: 38 mm · Manufacturer: GPO · Manufacturer: NGK · Manufacturer: swiing® ingenious parts · Displacement: 50 ccm · Crankshaft stroke: 42 mm · Hole spacing inlet: 32 mm · Ø piston pin (B): 12 mm · Outlet type: clamped · Hole pattern [mm]: 60 x 40 · Decompressor: No · Camouflaged: No · Area of application: Tuning

swiing® ingenious tuning cylinder 38 mm | Sachs 503

Nominal diameter: 38 mm · Manufacturer: swiing® ingenious parts · Material: Aluminum · Surface: sandblasted · Displacement: 50 ccm · Crankshaft stroke: 42 mm · Thread inlet: M6x1 (standard thread) · Hole spacing inlet: 32 mm · Ø piston pin (B): 12 mm · Outlet type: clamped · Number of fixing points: 4 pcs · Hole pattern [mm]: 60 x 40 / 37 x 37 · Decompressor: No · Camouflaged: No · Area of application: Tuning

swiing® ingenious tuning cylinder 40 mm | Sachs 503

Nominal diameter: 40 mm · Manufacturer: swiing® ingenious parts · Material: Aluminum · Surface: sandblasted · Displacement: 55 ccm · Crankshaft stroke: 42 mm · Thread inlet: M6x1 (standard thread) · Hole spacing inlet: 32 mm · Ø piston pin (B): 12 mm · Outlet type: clamped · Number of fixing points: 4 pcs · Hole pattern [mm]: 60 x 40 / 37 x 37 · Decompressor: No · Camouflaged: No · Area of application: Tuning

swiing® ingenious tuning set 40 mm | Sachs 503 (fan-cooled)

Nominal diameter: 40 mm · Manufacturer: GPO · Manufacturer: NGK · Manufacturer: swiing® ingenious parts · Displacement: 55 ccm · Crankshaft stroke: 42 mm · Hole spacing inlet: 32 mm · Ø piston pin (B): 12 mm · Outlet type: clamped · Hole pattern [mm]: 60 x 40 · Decompressor: No · Camouflaged: No · Area of application: Tuning
