GPO brake cam & retaining plate set | Puch Maxi N

GPO control bearing set M26x1 mm | Puch

Bearing type: Bearing ring · Ø outside: 41 mm · Manufacturer: GPO · Material: Steel · Surface: galvanized (blue) · Color: silver · Ø inside: 26.8 mm · Thread type: MF26x1 (fine pitch thread) · Ø mounting frame: 31 mm

swiing® revival 17" rear fender Inox | Puch Maxi N

Manufacturer: swiing® revival parts · Material: Chrome steel (stainless steel) · Surface: polished · Color: Chrome · Folding the ends: closed folded · Folding the ends: not folded · Shape of the mudguard: angular · Mounting type: Nuts & bolts · Total length over ends: 625 mm · Scope: 940 mm · Wide mudguard profile: 82 mm · Height of mudguard profile: 35 mm · Total height from support surface to top edge: 285 mm · Wheel size [inch]: 17 "

Fuel tap horizontal M12x1 (with union nut) outgoing at the bottom

Possible lever positions: open / closed / reserve · Material lever: Metal · Thread type: MF12x1 (fine pitch thread) · Filter type: Plastic net · Installation direction: horizontal / horizontal · Outlet direction: below · Spare tube shape: curved · Mounting type: Union nut · Ø fuel hose connection: 6 mm · Reserve level: 70 mm

GPO rear mudguard attachment 17" | Puch Maxi N

Material: Steel · Color: Chrome · Number of fixing points: 4 pcs · Ø mounting hole: 6 mm · Manufacturer: GPO · Surface: chrome-plated · Mounting type: Nuts & bolts · Wheel size [inch]: 17 " · Total length: 300 mm

swiing® revival frame guard black | Puch Maxi N

Manufacturer: swiing® revival parts · Material: Plastic · Surface: raw · Mounting type: Plug connection · Number of fixing points: 1 pcs · Total length: 175 mm · Width: 54 mm · Height: 20 mm · Ø mounting hole: 21.5 mm · Color: black

Exhaust mounting plate | Puch Maxi N

Manufacturer: Made in Portugal · Material: Steel · Surface: galvanized (blue) · Ø mounting hole: 8.5 mm · Ø mounting hole: 11 mm · Cranking (offset): 23 mm · Number of fixing points: 2 pcs

GPO side bars chrome | Puch Maxi N

Manufacturer: GPO · Material: Steel · Surface: chrome-plated · Total length: 360 mm · Height: 60 mm · Width: 140 mm · Mounting type: Screws · Hole spacing: 342 mm · Number of fixing points: 2 pcs · Color: Chrome · Ø mounting hole: 8.1 mm

GPO Brake support bolt short Inox | Puch Maxi, Supermaxi

Manufacturer: GPO · Ø shaft: 9.8 mm · Material: Chrome steel (stainless steel) · Drive: Outer edge · Width across flats SW: 13 mm · Ø External head: 14 mm · Width across flats SW: 17 mm · Thread type: MF10x1 (fine pitch thread) · Shank: Yes · Shank length: 9.5 mm · Total length: 32 mm · Thread length: 13 mm · Number of components: 3 pcs · Area of application: Standard

swiing® revival rear brake anchor plate | Puch Maxi N

Manufacturer: swiing® revival parts · Ø shaft: 10 mm · Material: Steel · Surface: galvanized (blue) · Ø External brake pads: 80 mm · Total length: 135 mm · Ø bore: 12.2 mm · Brake lever length (lever length): 68 mm · Ø axle: 12 mm · Ø screw holder: 6.5 mm · Wide cam holder: 12 mm · Ø outside: 92 mm · Cranking (offset): 10 mm

Screw M5x16 countersunk head Inox

Drive: Slot · Material: Chrome steel (stainless steel) · Total length: 16 mm · Screw head: Countersunk head · Thread type: M5x0.8 (standard thread)
