swiing® ingenious 0.5 mm lifting plate aluminum original | Puch

GPO 38 mm cylinder head original | Puch Maxi S, N / X30 NS, NL, N-2AH

Width: 125 mm · Height: 55 mm · Manufacturer: GPO · Material: Aluminum · Surface: sandblasted · Ø cylinder: 38 mm · Area of application: Standard · Candle thread: short · Hole pattern [mm]: 44 x 44 · Total length: 135 mm · Number of fixing points: 4 pcs · Decompressor: No

Elring Curil T2 sealing compound 70 ml green (polyurethane) non-hardening

Manufacturer: Elring · Area of application: Chemistry · Contents [ml]: 70 ml · Color: green · Temperature resistance (min.): -55 - 250 °C · Gap dimension (max.): 0.2 mm

Outlet gasket 18 - 22 mm metal ring

Ø inside: 22 mm · Place of use: Outlet · Material: Sealing carton · Material: Sheet metal (steel) · Thickness: 2 mm · Ø mounting hole: 6.7 mm · Hole spacing: 38 - 42.5 mm · Number of fixing points: 2 pcs

MBR retaining plate oil seal on ignition side "Racing" Inox

Manufacturer: MBR · Ø inside: 25.3 mm · Material: Chrome steel (stainless steel) · Surface: brushed · Color: silver · Ø outside: 89.4 mm · Area of application: Tuning · Number of fixing points: 4 pcs

Meteor piston pin lock Ø 12 mm (double)

Manufacturer: Meteor · Material: Spring steel · Surface: blank · Number of sensors / lugs: 2 pcs · Ø outside: 12 mm · Pony spare part no.: A1632 · Sachs spare part no.: 0245 000 000 · Tomos spare part no.: 032039

swiing® ingenious 0.5 mm lift plate aluminum tuning | Puch

Manufacturer: swiing® ingenious parts · Material: Aluminum · Area of application: Racing · Surface: anodized · Ø cylinder: 45 mm · Thickness: 0.5 mm · Place of use: Cylinder base

GPO 38 mm cylinder head gasket 0.2 mm | Puch

Manufacturer: GPO · Material: Aluminum · Place of use: Cylinder head · Ø cylinder: 38 mm · Area of application: Original · Area of application: Standard · Thickness: 0.2 mm · Ø screw holder: 7 mm · Alternative version of the Puch spare part no.: 349.1.10.004.1

swiing® ingenious crankshaft High End (+1 mm stroke) (Version 2.0) | Puch E50

Manufacturer: swiing® ingenious parts · Area of application: High End · Material: Aluminum · Cheek type: Full cheeks · Material: Steel · Crankshaft stroke: 44 mm · Connecting rod length center-center: 90 mm · Thread length: 11 mm · Thread length: 15 mm · Total length of crankpin on clutch side: 74 mm · Weight: 970 g · Total length crankpin ignition side: 66 mm · Ø crank webs: 69.9 mm · Ø piston pin (B): 12 mm · Ø Connecting rod eye: 15 mm · Ø Bearing seat (clutch side): 17 mm · Thread type: MF10x1 (fine pitch thread) · Ø Bearing seat (ignition side): 17 mm · Dimension needle bearing: 12 / 15 x 14.2 mm (axe 12) · Wide crank webs: 34 mm · Length 1st paragraph: 9 mm · Length 2nd paragraph: 14.5 mm · Length 3rd paragraph: 25 mm · Ø 1st step (on the coupling side): 22 mm · Ø 2nd shoulder (on the clutch side): 17 mm · Ø 3rd step (on the clutch side): 15 mm · Length of shoulder (ignition side): 26.3 mm · Number of gears: 1 pcs

swiing® ingenious crankshaft High End C3/4 & Viton (+1 mm stroke) (Version 2.0) | Puch E50

Dimension needle bearing: 12 / 15 x 14.2 mm (axe 12) · Manufacturer: swiing® ingenious parts · Material: Steel · Cheek type: Full cheeks · Thread type: MF10x1 (fine pitch thread) · Crankshaft stroke: 44 mm · Connecting rod length center-center: 90 mm · Weight: 970 g · Total length of crankpin on clutch side: 74 mm · Total length crankpin ignition side: 66 mm · Ø crank webs: 69.9 mm · Area of application: High End · Ø Connecting rod eye: 15 mm · Thread length: 11 mm · Thread length: 15 mm · Ø piston pin (B): 12 mm · Ø Bearing seat (clutch side): 17 mm · Ø Bearing seat (ignition side): 17 mm · Wide crank webs: 34 mm · Length 1st paragraph: 9 mm · Length 2nd paragraph: 14.5 mm · Ø 1st step (on the coupling side): 22 mm · Ø 2nd shoulder (on the clutch side): 17 mm · Ø 3rd step (on the clutch side): 15 mm · Length of shoulder (ignition side): 26.3 mm · Number of gears: 1 pcs

GPO cylinder stud bolt set special M6x106 mm galvanized | Puch

Manufacturer: GPO · Material: Steel · Surface: blue galvanized · Diameter: 7 mm · Thread type: M6x1 (standard thread) · Total length: 106 mm · Drive: External hexagon · Width across flats SW: 10 mm · Thread length: 15 mm · Thread length: 19 mm · Strength class: 10 · Strength class: 10.9 · Alternative version of the Puch spare part no.: 360.1.10.034.1
